Soil preparation machine up to a depth of 120-150 mm, for tractors with Vario between 80 – 120 HP. Transforms forest land, with stumps and rocks, in land for cultivation avoiding accidents in later processes.
Characteristics
Steel-plate chassis, thickness 8 mm.
Rotor FIXE TOP of Ø 470 mm.
Gearbox SERRAT for 120 HP.
4 XPC belt transmission.
Supports of bearing rotor in steel.
Oscillating bearings of double row of rollers.
PTO 540 rpm.
Rear hydraulic hood.
Protection chains.
Chassis internal reinforcements, thickness 10 mm.
System antiwire in rotor.
Compact drive cover.
Rear roller into the hood.
Model built under EC Normative.
Safety indicators visible to personnel.
Advantages Serrat
TILLER 3 IN ACTION
REAR HYDRAULIC HOOD
COMPACT DRIVE COVER
FIXE TOP SYSTEM
CENTRALIZED GREASING
