Forestry heavy brush culter with unit-body construction of 10 mm of thickness. Gearbox up to 120 HP.
Suitable for work of clearing brush, creation of grassland, follow fields and electrical lines, with bushes in foot up to 60 mm.
Frame with unit-body construction. Top reinforcements and plates antispoil lower, to avoid the shock of the chains against the chassis of 5 mm.
Plate with system of anchorage of chains with linkage parts, diameter 16 mm.
Characteristics
Steel-plate closed chassis, thickness of 10 mm + 5 mm.
PTO 540 rpm.
SERRAT rotor with 4 chains with links of Ø 16 mm.
Front protection curtain.
Lower reinforcements (links of chains).
Top reinforcements.
Height-adjustable skid shoes.
Transmission with freewheel.
High-power gearbox.
Model built under EC Normative.
Safety indicators visible to personnel.
FXCS IN ACTION
SERRAT DISH WITH INTERCHANGEABLE CHAINS
